Wrap and Roll – Part I – Faraday

In case you ever have interacted with external APIs, you most likely have noticed that not all SDKs or connections are created equal, more often than not they can be confusing, and hard to deal with, but that can and will change when you decide to wrap, encapsulate and abstract the behavior of an API.

I’ve decided to follow step by step on how a wrapper is devised, from studying the API to understanding how it will work. For that same reason, I’ve decided to make this a two-part blog post! In this first part we’ll talk about the wrapping logic, and the next post will be about the testing!

Intro

Here you’ll learn the basics of wrapping and what this means from a general standpoint. Why does it make sense? why does it make it easier? and most importantly… how do I do it?

Well, in this regard we’ll be using two really cool gems, Faraday and VCR. Faraday is an HTTP client library abstraction layer that can be used with many adapters (you can choose the one you like the most!). It uses middleware to process requests and responses from the web and can be very intuitive to use.

VCR, on the other hand, is our ally on the testing front of things, it can record your HTTP interactions and replay them when running tests, so you’ll have accurate and deterministic tests!

So, let’s start by talking about Faraday!

Why Faraday?

Faraday can save lots of time by providing already developed tools while using the adapter of your choice, instead of directly using Net::HTTP, HTTPClient, and so forth, we can instead rely on the features already provided to build dryer code and abstract the ins and outs of how a HTTP request is made.

Just by making a simple setup, we have access to keep-alive connections, parallel requests, automatic parsing (even using your desired parser!), customization of how the request/response cycle is handled via middleware and so on!

At the end of the day, it ends up being a quality-of-life upgrade for creating connections to APIs.

Remember to check the Faraday Docs for more detailed info!

What is a Wrapper

So… what is a wrapper?

The point of a wrapper is to make the life of a developer easier. It facilitates the way you interact with an API and its protocols, and it encapsulates its behavior making it easier to understand and test them.

When you use a simple API your life feels like a breeze, no problems, no setbacks, no head scratching, only manual labor to set up a lot of different requests, but when there is an overly complicated API, with endless amounts of endpoints and bodies, protocols here and there… it’ll make you rethink your life choices on the area you chose as a career, a wrapper ends up being a package that wraps the API calls in simple to understand and use class or classes, without relying on an adapter to set configurations and initiate a different connection every time you need to create a different endpoint, it also makes it easier to automate responses in your projects.

When you create your wrapper, you’ll define the set of functions you’ll have, you define the endpoints that will be used, and adapt the way you call them to the reality of your application, so it can also substitute an existing SDK that has much more tools than you need, or maybe the tools provided are not useful enough!

TL;DR:

In that line, an API wrapper is a language-specific package or kit that encapsulates multiple API calls to make complicated functions easy to use. It helps developers call various APIs without the need for their real-time interaction. As such, wrappers can be used to automate API-reliant processes. Since APIs allow users to access a set of specific standard functions, API wrappers can help you integrate multiple API calls into a single service.

— https://rapidapi.com/blog/api-glossary/api-wrapper/

Basic Setup

For this example, we’ll be wrapping the PokeAPI! It’s a simple-to-use API for accessing all information about the Pokemon game or anime. Our application will store locally what we want, so think of it like a local pokedex if you will.

First, let’s create the Rails app without a testing framework

rails new pokedex -T

There we have it, the skeleton of our Pokedex!

The next step is to install the gem we will need, in this case, the Faraday gem

# Gemfile.rb
gem 'faraday'

Install the gems using:

bundle install

Done! Let’s start creating our wrapper!

Here we’ll follow rails conventions that are already in use by controllers, models, mailers, service and query objects, and such, so we’ll create an app/apis folder, inside it there will be the folder containing all logic for the API wrapper, let’s call it poke_api.

Since we’ll be using the V2 of the PokeApi is really important to organize the versions of your used APIs in different folders/modules, so when a new one is released you’ll just need to create a new folder and follow the same steps!

Finally, to represent the connection and contain the code per se, we’ll create a client.rb file inside app/apis/poke_api/v2, but feel free to name it however you see fit. The soul of our wrapper resides here!

Understanding the API and Creating our DB

Before effectively coding let’s explore the API, its endpoints, and what will be used. Every time you make an API Wrapper you need to know and study the API, otherwise how will it be useful?

In the docs, we learn that this is a consumption-only API, meaning there is only the GET method available for its resources, either way, we’ll learn about using the POST method later. There is also no need for authentication, all resources are readily available, and no rate limit is imposed!

We’ll tacke at three resources/endpoints: Pokemons, Berries and Items, they can are defined, respectively, as

-> GET https://pokeapi.co/api/v2/pokemon/{id or name}/
-> GET https://pokeapi.co/api/v2/berry/{id or name}/
-> GET https://pokeapi.co/api/v2/item/{id or name}/

For the Pokemon endpoint we’ll want to save the following information:

• Name: String
• Height: Integer
• Weight: Integer

For the Berry endpoint we’ll want to save the following information:

• Name: String
• Size: Integer
• Smoothness: Integer

For the Item endpoint we’ll want to save the following information:

• Name: String
• Cost: Integer

Let’s create simple models and migrations to represent them in our DB!

## Migrations
class CreatePokemons < ActiveRecord::Migration[7.1]
  def change
    create_table :pokemons do |t|
      t.string :name
      t.integer :height
      t.integer :weight

      t.timestamps
    end
  end
end

class CreateBerries < ActiveRecord::Migration[7.1]
  def change
    create_table :berries do |t|
      t.string :name
      t.integer :size
      t.integer :smoothness

      t.timestamps
    end
  end
end

class CreateItems < ActiveRecord::Migration[7.1]
  def change
    create_table :items do |t|
      t.string :name
      t.integer :cost

      t.timestamps
    end
  end
end

## Models
class Pokemon < ApplicationRecord
end

class Berry < ApplicationRecord
end

class Item < ApplicationRecord
end

We won’t deal with validations here since it’s not the objective, but don’t forget to do it!

Now that we have a basic understanding of the endpoint and what information we’ll extract, let’s start wrapping it up!

Wrapping (the API) Up

Firstly, let’s understand the basic functionality of the Faraday gem.

Even though we can create different functions, each with a direct call to the API via a quick request with Faraday.get, for example, there is a better and recommended option. The idea here is to create a Faraday Connection, an object that represents the API and will be responsible for calling it.

This connection by itself will allow us to define default headers, params, timeouts, a base URL and middleware! This will save us some time later and prevent some headaches. We can call this connection using HTTP verbs and passing the endpoint and body, even though Faraday accepts a lot of verbs here we will only use the GET and POST (we will imagine a POST endpoint for examples later)

We’ll create the object and pass it some parameters and options in the middleware defined in the yielded block.

The soul of the client will reside inside a client method as such:

# client.rb

require 'faraday'

module PokeApi
  module V2
    class Client
      POKE_API_BASE_URL = 'https://pokeapi.co/api/v2/'

      private

      def client
        @client ||= begin
          options = {
            open_timeout: 10,
            read_timeout: 10
          }
          Faraday.new(url: POKE_API_BASE_URL, **options)
        end
      end
    end
  end
end

Okay! Let’s dissect what we did here, then we will include more stuff.

We created a private method called client that memoizes a Faraday Connection to be used in the endpoint methods we will define later, we created an options hash to define a timeout option to both open and read, the best values will all depend on your application, but since we will use the default Faraday adapter Net::HTTP we know that the default initial timeout for open and read it is 60 seconds, but let’s use a lower value, we don’t want to wait up to a whole minute to get our response.

Next, we instantiated a Faraday Connection with .new passing the BASE URL and the options hash, and there we have it, a way to call the PokeAPI! But there is more!

Middleware

Let’s talk about the middleware. The real power of the Faraday Connection comes from this stack, it hooks into the request/response cycle and modifies it, with it we can add an authentication header, parse JSON responses, and log the request and response while filtering sensitive info, raise errors for 4xx and 5xx and so on!

With this image from the How it works section in the Faraday Docs we have the basic idea, for you curious developer on the ins and outs of the functionality.

For this application, we only want the parsing, logging without filtering if we need to debug (there is no sensitive info here), and raising of error when there is a problem, so our connection ends up like this:

def client
  @client ||= begin
    options = {
      request: {
        open_timeout: 10,
        read_timeout: 10
      }
    }
    Faraday.new(url: POKE_API_BASE_URL, **options) do |config|
      config.request :json
      config.response :json, parser_options: { symbolize_names: true }
      config.response :raise_error
      config.response :logger, Rails.logger, headers: true, bodies: true, log_level: :debug
    end
  end
end

With config.request :json and config.response :json, parser_options: { symbolize_names: true } we are expecting a JSON request body (You can actually pass a hash and it will be parsed to JSON) and JSON responses, as for the response the parser will parse the keys as symbols, which is really convenient. Of course, you could use a different parser instead of the Rails default, like OJ, in this case just follow this doc, it’s pretty easy!

With config.response :raise_error Faraday will raise a Faraday::Error exception if an HTTP response returns with a 4xx or 5xx, which can help understand the flow of the code and deal with them with rescue clauses. This end up being a personal preference, but I do recommend using it, this way the wrapper can rescue them and raise a custom general ApiError for example, it will call the attention to the error, which is vital IMHO, more on that in the next part of this blog post when we deal with error and testing.

Last but not least, with config.response :logger, Rails.logger, headers: true, bodies: true, log_level: :debug we will log to the Rails logger the request and the response body and headers, it can also be configurated to filter sensitive info like secret keys and confidential information, it’s not the case here, but just a heads up! With logging you can debug any problems involving the request/response cycle. I recommend always using this middleware.

You can get to know more about all middlewares in their middleware official docs, you can see the best options and adapters for your case!

Important information, even though in the docs there is no mention of the importance of the middleware order, there is a common pitfall that makes you unable to log errors, so watch out! more info in this section of a recommended blogpost by the Faraday devs.

Adding Endpoints to the Wrapper

Okay! Great work catching up until now! We can finally make our endpoints, first let’s make a private request method that will always call the connection with the desired HTTP verb, endpoint, and body.

private

def client
  #...
end

def request(http_method:, endpoint:, body: {})
  response = client.public_send(http_method, endpoint, body)
  {
    status: response.status,
    body: response.body
  }
end

What is happening here? Well, this private method will be used in our endpoint methods! With it, we will use public_send to invoke our desired verb (which to the Faraday connection is used as a method), and with it sends our endpoint and params as its arguments.

This means:

# This:
request(:get, 'pokemon/pikachu', { stuff: "stuff" })

# Translates to:
client.get('pokemon/pikachu') do |request|
  request.body = { stuff: "stuff" }
end

## => GET https://pokeapi.co/api/v2/pokemon'
## => body: { "stuff": "stuff" }

When we get our response it will be stored in a hash containing the status and the body, if there is any problem (4xx or 5xx) an error will be raised, so we will rescue it:

def request(...)
# ...
rescue Faraday::Error => e
  puts e.inspect
end

For now, we will only print the result, but there will be better treatment in the next part of this blog!

You will see in a second how all of this is useful! Let’s create now our first method for the Pokemon endpoint!

# Let's name it accordingly
def get_pokemon(pokemon_name)
  # Now we only call the request method
  request(
    http_method: :get,
    endpoint: "pokemon/#{pokemon_name}"
  )
end

Done.

We have a functioning wrapper! Let’s manually test it with the rails console before moving to the other endpoints.

$ connection = PokeApi::V2::Client.new
=> #<PokeApi::V2::Client:0x00007f150d9f81d8>

$ response = connection.get_pokemon('spirigatito')
=> GET https://pokeapi.co/api/v2/pokemon/sprigatito
   User-Agent: "Faraday v2.9.0"
   Status 200
   date: "Thu, 21 Mar 2024 17:41:53 GMT"
   content-type: "application/json; charset=utf-8"
   connection: "keep-alive"
   ...
   { // Response body is here }

$ response[:status]
=> 200

$ response[:body]
=> {
      abilities: [...],
      base_experience: nil,
      cries: {...}
      height: 4
      moves: [...]
      ...
   }

$ response[:body][:name]
=> "spirigatito"

Pretty cool, right? Even though it demanded some heavy work to comprehend what happens in the back end, now that we have a functioning wrapper we can get any Pokemon we want!

That is the gist of it, we create a connection, call the desired method that represents an endpoint, and access it as a hash when we get a response!

But what if we search for a Pokemon that does not exist?

$ response = connection.get_pokemon('agumon')
=>  User-Agent: "Faraday v2.9.0"
    Status 404
    date: "Thu, 21 Mar 2024 17:57:20 GMT"
    ...
    Not Found

    /.../faraday/response/raise_error.rb: the server responded with status 404 (Faraday::ResourceNotFound)

We receive an exception raised by Faraday based on the 404 response we got from the API! In the next part of this blog, we’ll deal with error handling, so don’t sleep on it for now!

Anyways, let us finish the other endpoints:

# client.rb
def get_berry(berry_name)
  request(
    http_method: :get,
    endpoint: "berry/#{berry_name}"
  )
end

def get_item(item_name)
  request(
    http_method: :get,
    endpoint: "item/#{item_name}"
  )
end

Simple, right? This pattern keeps on coming back each time you make a new method, and the way you call it is the same as mentioned before! Of course, we are dealing with the GET verb, surely the other verbs are hard to grasp… Well, no!

Let’s imagine that this API accepts a post request that registers a new Pokemon of your creation, let’s use the same endpoint as the GET Pokemon one, we just need a body and to use the POST verb.

# client.rb
def create_pokemon(params)
  request(
    http_method: :post,
    endpoint: '/pokemon',
    body: {
      name: params[:pokemon_name],
      height: params[:pokemon_height],
      weight: params[:pokemon_weight],
      locations: {
        # ...
      }
    }
  )
end

That’s it! If it was a real endpoint, we only have to call like we did before, but using a hash as an argument, the body would be parsed and converted to JSON and it would be done! If your wrapper API has a lot of POST methods with lots of bodies you could even make a module with request bodies and then call it, in this example, it would be something like:

def create_pokemon(params)
  ...
  body: RequestBodies::Pokemons.create_pokemon(params)
end

Neat and organized, as all things should be 😀

What now?

Well, now that we have a functioning wrapper we can do whatever we want, in this application we could use a callable service approach, it would call the wrapper, get its response, and use it to save the information to our DB. Since it’s not the focus of this blog post, I’ll write an example and leave it in the repository for you to read if you want, but just for shows, it would be something like

# app/services/application_service.rb
class ApplicationService
  def self.call(...)
    new(...).call
  end
end

# app/services/pokemons/get.rb
module Pokemons
  class Get < ApplicationService
    def initialize(pokemon_name, connection)
      @pokemon_name = pokemon_name
      @connection = connection
    end

    def call
      @connection.get_pokemon(@pokemon_name)
    end
  end
end

# app/services/pokemons/save.rb
module Pokemons
  class Save < ApplicationService
    def initialize(pokemon_name)
      @pokemon_name = pokemon_name
    end

    def call
      response = Pokemons::Get.call(@pokemon_name, faraday_connection)

      pokemon = Pokemon.new(
        name: response[:body][:name],
        height: response[:body][:height],
        weight: response[:body][:weight]
      )

      pokemon.save!
    end

    private

    def faraday_connection
      @faraday_connection ||= PokeApi::V2::Client.new
    end
  end
end

# Rails Console

$ Pokemons::Save.call('sprigatito')
=>  GET https://pokeapi.co/api/v2/pokemon/sprigatito
    User-Agent: "Faraday v2.9.0"
    Status 200
    date: "Thu, 21 Mar 2024 18:30:10 GMT"

      TRANSACTION (0.1ms)  begin transaction
      Pokemon Create (0.4ms)  INSERT INTO "pokemons" ("name", "height", "weight", "created_at", "updated_at") VALUES (?, ?, ?, ?, ?) RETURNING "id"  [["name", "sprigatito"], ["height", 4], ["weight", 41], ["created_at", "2024-03-21 18:30:10.376862"], ["updated_at", "2024-03-21 18:30:10.376862"]]
      TRANSACTION (0.1ms)  commit transaction

$ Pokemon.last
=>  id: 1,
    name: "sprigatito",
    height: 4,
    weight: 41,
    created_at: Thu, 21 Mar 2024 18:30:10.376862000 UTC +00:00,
    updated_at: Thu, 21 Mar 2024 18:30:10.376862000 UTC +00:00>

Again, that’s just an overengineered use example, remember to always use the best for your needs! But if you’re curious about the callable way, read this blog post!

Conclusion

Today, we’ve learned how effective it is to have your API wrapper. You now can have control over the APIs you choose to work with! Less headaches and more time to take naps, all thanks to Faraday! We saw how powerful a Faraday Connection is, with its middlewares that hook into the request/response cycle and facilitate the heavy lifting of configuration and parsing. Don’t worry about memorizing all this information the best way to learn is to understand what you are reading and consult documentation and blog posts when needed. Think of all this as a new skill in your toolbox!

Next time we talk, we will study how to test this wrapper using VCR and discuss why we are using VCR instead of Webmock, we will create the tests and compare them with testing with real requests all the time. See you in the next one!

Check out the source code for this blogpost here.
